MB TBC25-1-5/8 Bearing Unit 1-5/8″ ID TBC251-5/8 TBC25158 Tapped Base USA

USD 71.86 USD

SKU: Yy7Jxkfl

Brand: MB

MPN: TBC25 1-5/8

GTIN: 662864009843

Condition: New

Tags: -20 °C 1-5/8" 1.625 in 100 °C 20.4 kN / 4586 lbf 32.5 kN / 7306 lbf 4000 rpm 662864009843 ABEC 1 / P0 Ball Cast Iron Double Rubber Seal Flanged Mount Bearing Grease MB Non-Expanding Spherical Standard Duty Straight TBC 25 1-5/8 TBC20 TBC25 1-5/8 United States Yes

Categories: Envelopes & Mailers

Specifications

Model	TBC 25 1-5/8
Type	Flanged Mount Bearing
MPN	TBC25 1-5/8
Bore Diameter	1.625 in
Material	Cast Iron
Country Of Origin	United States
Min Temp	-20 °C
Seal Type	Double Rubber Seal
Dynamic Load Rating	32.5 kN / 7306 lbf
Static Load Rating	20.4 kN / 4586 lbf
Limiting Speed	4000 rpm
Bore Type	Straight
Lubricant	Grease
Precision Rating	ABEC 1 / P0
Series	TBC20
Housing Material	Cast Iron
Duty Type	Standard Duty
Expansion Type	Non-Expanding
Insert Outer Ring	Spherical
Relubrication Feature	Yes
Rolling Elements	Ball
Max Temp	100 °C
UPC	662864009843

MPN: TBC25 1-5/8. Type: Flanged Mount Bearing. Pillow Block Unit - 1.625 Bore, 2 bolt, Cast Iron, Standard Duty, Non-Expanding. Dodge NSTU-SC-112 Take-Up Bearing Unit 1-3/4" ID 125258 NSTUSC112. Browning MTWS-223 Take-Up Bearing Unit 1-7/16" ID MTWS223.
